MAMBA X ESC W / 1515-2200KV SENSORED 1:8 E-BUGGY EDITION
CURRENT LEAD TIME: 2-3 WEEKS
The Mamba X represents the latest and greatest in Castle Creations Inc. ESC technology. Originally designed to overpower 1:10th scale buggies and trucks, the ROAR APPROVED Mamba X also delivers amazing race capabilities for 1:8th scale eBuggy. After being extensively race-tested by Castle Creations' Lead Mechanical Engineer and Team Driver, Taylor James - the Mamba X has been approved for eBuggy racing with two of our most popular 15 Series Motors.
This combo is a Mamba X ESC and 1515 1Y 2200kv motor for lighter 1/8th scale applications. Normally this motor is paired with our 1/8th scale Mamba Monster X ESC; but if you need to save some weight or need a smaller footprint, the Mamba X is more than capable of running this motor. This setup is recommended for 3s or 4s use in a vehicle weighing less than ~9lbs and geared for no more than ~45 MPH. If you have a heavier vehicle, looking for more speed or just want to beat the ever loving snot out of your vehicle we would recommend picking up the Mamba Monster X combo (P/N 010-0145-03).
ESC FEATURES:
|
|
MOTOR FEATURES:
|
|
MAMBA X MAMBA X W/1515-2200KV SENSORED 1:8 E-BUGGY EDITION COMBO COMES WITH:
|
|
Specification
Model information
| Technical Specs | |
|---|---|
| Controller: | |
| Input Voltage Range: | MIN: 2S LiPo MAX: 6S LiPo (25.2V) (Max 4s with included motor) |
| BEC Specifications: | Adjustable: 5.5V, 6.0V, 7.5V. or 8.0V (8A Peak), default 5.5V |
| Operating Environment: | Waterproof* design allows for use in nearly any environment. |
| Brake: | Proportional |
| Reversible: | Yes, but may be disabled for racing. |
| On/Off Switch: | Yes |
| Cooling Fan: | Yes, factory equipped (30mm), fully removable** (see Product Use Statements below) |
| Size: | Length: 2.14" (54.4mm) Width: 1.39" (35.2mm) Height: 1.18" (30.0mm) |
| Weight (with wires): | 3.56 oz. (101g) |
| Connectors: | 4.0mm female bullets for motor connection. |
| Items Needed for Operation: | Battery Connector required, Castle 6.5mm Polarized Connectors, Castle 4.0mm Polarized Connectors, Traxxas® Power Connectors, or Deans® Ultra Plugs are recommended. |
| Product Use Statements: | *Although Mamba X is waterproof, it is not intended for operation while completely submerged in liquid. Always rinse the ESC and motor with clean water after exposure to corrosives or dirt. While the motor and controller may be waterproof, we suggest users confirm that the rest of their vehicle, including the batteries, servos, radio and chassis are also waterproof before exposing them to liquids of any kind. **The cooling fan must be removed prior to driving in wet conditions. It is not waterproof. |
| Application Guidelines: | Intended for up to 4s (25.2 Volt) operation in vehicles weighing less than 9bs/4kg with 1515 - 2200kv motor. SW VS. 1.82 ROAR APPROVED |
| Max. Recommended Vehicle Weight: | Less than 9bs/4kg, with batteries, ready-to-run. |
| Programmability: | Fully programmable Castle feature set using Castle Link USB adapter (coupon for free link included in package) and freely downloadable Castle Link Windows software or the Castle Link iOS App and a B-LINK Bluetooth Adapter (sold separately). |
| Telemetry Link Capable: | Yes, with purchase of the Castle Telemetry Link for S.BUS2 and a compatible transmitter. |
| Tech Notes: |
|
| Motor | |
|---|---|
| Input Voltage Range: | 3-6S LiPo; 4s maximum with Mamba X ESC |
| Kv: | 2200 |
| Max. RPM: | 60,000 |
| Size: | Length: 75.4mm Diameter: 40mm (41.4mm with fins) |
| Weight (w/wires): | 429g / 15.1oz |
| Shaft Size: | Length: 20mm Diameter: 5mm |
| Mounting Hole Specifications: | M3 and M4 @ 25mm |
| Cooling Fan: | Optional, coming soon! |
| Connectors: | 4mm male Castle Bullet Connectors on 12AWG wire, includes 210mm length sensor wire. |
| Application Guidelines: | Ideal for 1:8 scale off-road and on-road vehicles as well as 1:10 scale 4WD SCT up to 9lbs on 4s LiPo. |
| Max. Recommended Vehicle Weight: | See application guidelines |
| Tech Notes: | Running modes: SMARTSENSE™, Sensored only Water Resistant Design: The sensor board is coated with silicone conformal coating to protect the sensors from moisture. The sensor connections are not water resistant; water can cause signal loss which could result in loss of sensored capabilities. Castle recommended applying dielectric grease to the outside of the sensor wire connections after installation of the wire. Routine maintenance is recommended after running in wet conditions. Please refer to this document for running and maintaining motors in wet environments. |
